Yocan DeLux Vaporizer Manual

Preparing the Yocan DeLux Vaporizer

1. Make sure that you fully charge your Yocan DeLux Vaporizer before use.
2. Once the battery is charged, power the Yocan DeLux Vaporizer on by pressing the power button 5 times. Note: The power button is located at the back of the battery where you have the part where the slot for the smaller cartridge is facing outwards. The power button is the rectangular button at the back.
3. After the Yocan DeLux Vaporizer is powered on you can start the sterilization process for the Yocan DeLux’s Quart Dual Coils (QDC). YThe coils can be sterilized by pressing and holding the power button for 5 seconds. Repeat this process two or three times. Note: perform sterilization during the first time you receive your Yocan DeLux Vaporizer. This will eliminate and get rid of any impurities that might have made its way to the heating chamber during the manufacturing process.
4. After sterilizing the coils (QDC), let the vaporizer rest and sit for about 2 – 3 minutes. After so, you can begin loading your select concentrates onto your Yocan DeLux Vaporizer.

Loading the Yocan DeLux Vaporizer Quartz Dual Coils (QDC)

1. Prepare your concentrates, set them on a parchment paper or place them on a jar. Prepare your dab tool so you can easily scoop your concentrates to load the QDC.
2. If it’s the first time you’re using your Yocan DeLux Vaporizer, be sure to sterilize it first. Note: Follow steps for preparing the Yocan DeLux Vaporizer.
3. Pull the mouthpiece upwards to expose the Yocan coils.
4. Twist the coil caps counter clockwise to expose the Yocan QDC. The coils that are safely covered by the coil cap.
5. Load your desired amount of concentrate atop the coil. Note: Make sure that the dab tool does not touch the coils as contact with another metal may cause the coils to break or get damaged. Simply drop the concentrates atop the post located at the middle of the Yocan Quartz Dual Coils.
6. Replace the coil cap in place by twisting it clockwise. Note: make sure not to overtighten the threaded connection as it could damage it and cause it to be loose altogether.
7. Return the mouthpiece by sliding it back and assemble the Yocan DeLux Vaporizer.

Loading the Yocan DeLux Vaporizer E-Liquid Cartridge

1. Remove the e-liquid cartridge from the e-liquid battery by pulling it out. The cartridge is connected to the battery by a magnetic connection.
2. Once the e-liquid cartridge is removed, twist the cap located at the top of the cartridge counter clockwise.
3. Proceed by filling the cartridge with our select e-liquid blends.
4. Replace the cap and tighten the threaded connections.
5. Reseat the cartridge to the battery and wait till you hear the magnetic connections snap back shut.

Vaping with the Yocan DeLux Vaporizer

1. Make sure that the Yocan DeLux Vaporizer is charged, sterilized, and is loaded with your select materials before you begin vaping.
2. Once the Yocan DeLux Vaporizer is loaded, assume to press your lips on the mouthpiece and prepare to inhale.
3. Press and hold the power button of the Yocan DeLux battery, wait till the Yocan DeLux Vaporizer begins producing vapors and pull from the mouthpiece.
4. Repeat this process as necessary or as the concentrates or the e-liquid is fully consumed.

Care and Maintenance of the Yocan DeLux Vaporizer

The Yocan DeLux Vaporizer was made with several parts with different ways to clean and to maintain. To ensure your Yocan DeLux Vaporizer runs in good working condition and is kept clean, follow the steps below.

1. Press the power button 5 times to turn the Yocan DeLux Vaporizer on. Five clicks turns the Yocan DeLux Vaporizer back off.
2. Turn the Yocan DeLux Wax Concentrate Vaporizer upside down.
3. Proceed with a burn-off by pressing and holding the power button for 5 seconds. Repeat this process twice or thrice. The burn-off will melt and dissolve any residue making the cleaning process easy.
4. Let the vaporizer cool down.
5. Disassemble the Yocan DeLux Vaporizer by turning the threaded connections counter clockwise.
6. Wipe-off any liquid residue on the vaporizer with a dry paper towel and continue with reassembling the Yocan DeLux Vaporizer.
7. Check the e-liquid atomizer and check for damages. Decide whether to replace burnt coils.
