Yocan Flat 2.0 Dab Pen 510 Thread Battery Manual

Charging the Yocan Flat 2.0 Series Dab Pen Battery

1. Make sure to use a USB type-C charging to charge the Yocan Flat 2.0 Series Dab Pen Battery.
2. Connect the USB charging cable to a wall adapter and plug the wall adapter to a wall outlet.
3. Take the other end of the charging cable and connect it to the Yocan Flat 2.0 Series Dab Pen Battery.

Note: You can connect the charging cable to your computer or any compatible USB port to charge the Yocan Flat 2.0 Series Dab Pen Battery. The charging port is located at the side of the vaporizer. When charging, it is recommended that you remove the cartridge as the wax or oil might leak when the device is lying down.

Turning the Yocan Flat 2.0 Series Dab Pen Battery On

1. Make sure to fully charge the Yocan Flat 2.0 Series Dab Pen Battery for best results.
2. Press the power button of the Yocan Flat 2.0 Series Dab Pen Battery five times quickly to power it on.
3. Press the same power button for another five times to turn the Yocan Flat 2.0 Series Dab Pen Battery off.
4. Note: The power button is located at the upper part of the Yocan Flat 2.0 Series Dab Pen Battery, just right above the OLED screen. It is the circular button which is located on the front-facing part of the cartridge vaporizer.

Loading the Yocan Flat 2.0 Series Dab Pen Battery

1. Make sure to turn off the Yocan Flat 2.0 Series Dab Pen Battery by pressing the power button five times rapidly.
2. Once the Yocan Flat 2.0 Series Dab Pen Battery is powered off, simply connect the cartridge to the base of the battery and twist clockwise.
3. To remove the cartridge, twist it towards the opposite direction and carefully handle the cart until it comes off the threaded base.

Note: Avoid overtightening the cartridges as it might damage the threads. Twist it clockwise until you feel resistance on your fingers. Do not leave the cartridge with some play in it as it might cause the threads to become loose overtime.

Selecting the Temperature Level for the Yocan Flat 2.0 Series Dab Pen Battery

1. Make sure that the Yocan Flat 2.0 Series Dab Pen Battery is powered on.
2. Select your preferred temperature level by pressing either the + or - button.
3. Release the button when you have decided on the temperature level you want.

Note: The Yocan Flat 2.0 Series Dab Pen Battery has variable temperature settings with precise adjustment that range from 1.8 volts to 4.2 volts.

Maintenance and cleaning of the Yocan Flat 2.0 Series Dab Pen Battery

1. Make sure to remove the cartridge of the Yocan Flat 2.0 Series Dab Pen Battery.
2. Turn off the Yocan Flat 2.0 Series Dab Pen Battery by pressing the power button five times rapidly.
3. Take a cotton swab and wipe the cartridge contacts clean.
4. Use a dry paper towel and wipe the body of the Yocan Flat 2.0 Series Dab Pen Battery clean.
5. Follow the charging instruction and use the dedicated charging cable for the Yocan Flat 2.0 Series Dab Pen Battery to avoid battery damage.
6. Make sure to charge the Yocan Flat 2.0 Series Dab Pen Battery before storing it too long.

Note: Make sure to keep the parts dry before storing as it may cause mold buildup and may have negative effects if used. Use a dry paper towel or paper cloth after wiping the parts with a damp material, so as not to allow molds to develop on the device.
