Yocan Kodo Animal Series Box Mod Manual

Charging the Yocan Kodo Animal Box Mod

1. Take a USB Type-C charging cable and connect it to the port located at the bottom or base of the Yocan Kodo Animal Box Mod.
2. Take the other end of the charging cable and connect it to a power brick, and then plug it into a wall socket.

Note: Alternatively, you may connect the charging cable to a desktop, laptop, or a compatible game console to recharge the Yocan Kodo Animal Box Mod. The charging port is located on the bottom part of the device.

Preparing the Yocan Kodo Animal Box Mod

1. Make sure to fully charge the Yocan Kodo Animal Box Mod to get the best results.
2. After making sure that the battery is fully charged, hit the power button five times quickly to power on the Yocan Kodo Animal Box Mod.

Note: The power button is the tongue-like button located at the middle of the animal design.

Loading the Yocan Kodo Animal Box Mod Pre-filled Cartridge

1. Prepare your cartridge.
2. Link it to the 510-threaded connection.
3. Tighten the cartridge clockwise.
4. Stop when you feel sufficient resistance.

Loading the Yocan Kodo Animal Box Mod Refillable Cartridge

1. Prepare your wax concentrates or oils. Place them inside the cartridge using a dab tool or a unicorn bottle.
2. Seal the cartridge.
3. Link it to the 510-threaded connection.
4. Tighten the cartridge clockwise.
5. Stop when you feel sufficient resistance.

Note: Avoid removing the cartridge while the said part is still hot. It can affect the integrity of the components and it might cause minor burns on your finger.

Replacing the cartridge of the Yocan Kodo Animal Box Mod

1. Make sure that the Yocan Kodo Animal Box Mod is powered off and has cooled down.
2. Twist the mouthpiece counterclockwise.
3. Pick your cartridge, which could be pre-filled or refillable.
4. Connect the cartridge to the 510-threaded connection.
5. Twist it clockwise until you feel enough resistance.

Vaping with the Yocan Kodo Animal Box Mod

1. Make sure that you have fully charged the battery of the Yocan Kodo Animal Box Mod, installed your cartridge correctly, and loaded the device with your preferred wax concentrates or oil.
2. Press the power button five times quickly to activate the battery.
3. Press and hold the power button to vaporize your wax concentrates or extract in the cartridges.
4. Repeat this process as necessary or until the extracts in the cartridge are consumed.

Changing the voltage level of the Yocan Kodo Animal Box Mod

1. Make sure that the Yocan Kodo Animal Box Mod is powered on, press the power button five times quickly if it is still powered off.
2. Press the power button three times to cycle through the three voltage settings.
3. Once you have selected your preferred temperature level, leave the button and the device will automatically read your selection.

Yocan Kodo Animal Box Mod Voltage Levels:

• 2.5 volts (Blue Light)
• 3.0 volts (Green Light)
• 3.5 volts (Red Light)

Care and Maintenance of the Yocan Kodo Animal Box Mod

The Yocan Kodo Animal Box Mod is made with relatively few parts making it a device that’s easy to take care of. Follow the steps below on how you can clean and take care of your Yocan Kodo Animal Box Mod.

1. Wipe off any dirt or residue on the Yocan Kodo Animal Box Mod battery using a dry paper towel or some alcohol wipes. Continue to reassemble the vaporizer.
2. Follow the charging instructions and use the dedicated charging cable to prolong the Yocan Kodo Animal Box Mod.
3. For maintaining the coils, make sure to refrain from using any hard objects to tamper with the 510-threaded link. In the event of a damaged connection, refrain from using the Yocan Kodo Animal Box Mod.
