Yocan Stealth Vaporizer Manual

Preparing the Yocan Stealth Vaporizer

1. Make sure that you fully charge the Yocan Stealh Vaporizer before use.
2. Once you have secured a full charge, turn on the Yocan Stealth Vaporizer battery by clicking the power button 5 times. Note: The power button is located at the side part of the battery facing outwards just beside the micro USB charging port.

Loading the Yocan Stealth Vaporizer Concentrate Atomizer

1. Place your concentrates on a jar, a parchment paper, or any container where you can easily pick or scoop up your concentrates upon loading.
2. Press the metallic circular button at the side of the battery adjacent to the power button and the micro USB charging port. This will activate the switchblade functionality of the Yocan Stealth Vaporizer.
3. Once the switchblade function is activated, hold the wax concentrate chamber and twist it counter clockwise. This will detach the atomizer chamber from the battery itself and will allow you to safely load the wax concentrate atomizer.
4. Unscrew the bottom part of the concentrate atomizer chamber to reveal the atomizer coil.
5. Load desired amount of concentrate onto the coil. Note: Make sure that the dab tool does not touch the coils as contact with another metal may cause the coils to break or get damaged. Simply drop the concentrates atop atomizer coil.
6. Replace the bottom part and screw it back. Note: make sure that you do not overtighten the threads as it may damage it and cause it to be loose altogether.
7. Screw the atomizer chamber back to the battery.

Loading the Yocan Stealth Vaporizer E-Liquid Atomizer

1. Set your e-liquids aside where you can easily pick or take them up upon loading.
2. Press the metallic circular button at the side of the battery adjacent to the power button and the micro USB charging port. This will activate the switchblade functionality of the Yocan Stealth Vaporizer.
3. Once the switchblade function is activated, hold the e-liquid chamber and twist it counter clockwise. This will detach the atomizer chamber from the battery itself and will allow you to safely load the e-juice atomizer.
4. Unscrew the top part of the e-liquid atomizer chamber to access the filling hole.
5. Load desired amount of e-liquid onto the coil. Note: Make sure not to overfill the e-liquid atomizer chamber as it may result to spillage.
6. Replace the top part and screw it back. Note: make sure that you do not overtighten the threads as it may damage it and cause it to be loose altogether.
7. Screw the atomizer chamber back to the battery.

Vaping with the Yocan Stealth Vaporizer

1. Make sure that the Yocan Stealth Vaporizer is properly charged and is loaded before vaping.
2. Once loaded, bring the mouthpiece close to your lips and prepare to inhale.
3. Press and hold the power button at the same time to activate the heating mechanism and as the Yocan Stealth Vaporizer begins producing vapors, draw and pull from the vaporizer.
4. Repeat this process as necessary or as the concentrates or the e-liquids are fully consumed.

Switching Through the Temperature Settings

1. Power the Yocan Stealth Vaporizer on by quickly pressing the power button 5 times.
2. Tap the power button 3 times rapidly to select heat settings.
3. Release the power button to allow the selected heat setting to take effect on the Yocan Stix Vaporizer.

Below are the corresponding heat levels.

• Blue Light: Low Setting
• Green Light: Medium Setting
• Red Light: High Setting

Care and Maintenance of the Yocan Stealth Vaporizer

The Yocan Stealth Vaporizer has few parts with a few moving pieces which make it a solid device. This design and engineering make it easy to clean and maintain. To clean your Yocan Stealth Vaporizer, follow the steps below.

1. Disconnect the wax concentrate atomizer chamber and the e-juice chamber from the battery.
2. Check for damages and decide whether to replace the broken atomizer parts.
3. Wipe off the vaporizer and the parts with a dry paper towel.
