Yocan Vane 2 Portable Herb Vaporizer Manual

Charging the Yocan Vane 2 Dry Herb Vaporizer

1. Take the USB type-C charging cable included in the box.
2. Connect it to the Yocan Vane 2 Dry Herb Vaporizer battery.
3. Get a compatible wall adapter.
4. Plug the wall adapter to a wall socket.

Note: The charging port is located at the bottom part of the vaporizer. If you can’t find a wall adapter, you can connect it to your computer. Per the manufacturer, avoid charging the Yocan Vane 2 Dry Herb Vaporizer with a powerbank with an output higher than five volts. Do not charge in your car or overcharge the battery as this can result in battery damage and frying of the internal system.

Preparing the Yocan Vane 2 Dry Herb Vaporizer

1. Make sure to fully charge the Yocan Vane 2 Dry Herb Vaporizer.
2. When you have fully charged the battery, you can turn the Yocan Vane 2 Dry Herb Vaporizer on by pressing the power button five times rapidly.

Note: The power button is the square button on top of the LCD color display screen. Pressing the power button five times when powered on will cause it to turn off.

Loading the Yocan Vane 2 Dry Herb Vaporizer

1. Prepare your select herbs before using the Yocan Vane 2 Dry Herb Vaporizer. We recommend that you grind your herbs before use. You might want to consider using the Yocan Draco Mini.
2. Remove the magnetic mouthpiece by pulling it away from the Yocan Vane 2 Dry Herb Vaporizer base.
3. Load up your dry herbs on the herb chamber.
4. Replace the magnetic mouthpiece onto the body.

Selecting the Yocan Vane 2 Dry Herb Vaporizer Temperature Levels

1. Make sure to fully charge the Yocan Vane 2 Dry Herb Vaporizer.
2. Power the Yocan Vane 2 Dry Herb Vaporizer by pressing the power button five times rapidly.
3. When turned on, press the plus + button to increase the temperature level.
4. To lower the temperature setting, press the minus - button.

Note: The selected and running temperature level will be displayed on the aforementioned LCD color screen for owners to check during sessions.

Yocan Vane 2 Dry Herb Vaporizer Temperature range:

• 200 degrees Fahrenheit (93.33 degrees Celsius) to 480 degrees Fahrenheit (248.88 degrees Celsius).

Vaping with the Yocan Vane 2 Dry Herb Vaporizer

1. Make sure to fully charge the Yocan Vane 2 Dry Herb Vaporizer.
2. Load the Yocan Vane 2 Dry Herb Vaporizer with your preferred strain of dry herbs.
3. Select your desired temperature level.
4. Allow the Yocan Vane 2 Dry Herb Vaporizer to heat up and reach your selected temperature profile.
5. Inhale the vapors.
6. Repeat the process as necessary.

Care and Maintenance of the Yocan Vane 2 Dry Herb Vaporizer

1. Make sure to power the Yocan Vane 2 Dry Herb Vaporizer off.
2. Remove the magnetic mouthpiece.
3. Use the included brush to remove any ground material that might be stuck in the herb chamber.
4. You may also use the brush to clean the mouthpiece.
5. Get a dry paper towel or a cloth to clean the Yocan Vane 2 Dry Herb Vaporizer body.
6. Avoid draining the battery if storing the Yocan Vane 2 Dry Herb Vaporizer for a long time.
7. Only use the recommended charging cable and charge only through the recommended chargers to avoid damaging the battery of the Yocan Vane 2 Dry Herb Vaporizer.
