Yocan Zen Wax Vaporizer Manual

Charging the Yocan Zen Wax Vaporizer

1. Get a USB Type-C charging cable and connect it to the port located at the bottom or base of the Yocan Zen Wax Vaporizer.
2. Take the other end of the charging cable and connect it to a power brick, and then to a wall socket.

Note: The Yocan Zen Wax Vaporizer does not come with a USB Type-C cable so you will need to provide your own. You may connect the charging cable to a desktop, laptop, or a compatible game console to recharge the Yocan Zen Wax Vaporizer.

Preparing the Yocan Zen Wax Vaporizer

1. Make sure to fully charge the Yocan Zen Wax Vaporizer to get the best results.
2. After making sure that the battery is fully charged, hit the power button five times quickly to power on the Yocan Zen Wax Vaporizer.

Note: The power button is the rectangular button located right below the atomizer base with the airflow adjustment tool.

Loading the Yocan Zen Wax Vaporizer

1. Prepare your wax concentrates. Place them together with the inclusive dab tool that comes with the Yocan Zen Wax Vaporizer.
2. Remove the mouthpiece by pulling it away from the magnetic atomizer base.
3. Use your dab tool to scoop up your desired amount of wax concentrates and place it on top of your coil.
4. Replace the mouthpiece by sliding it back in pace.

Note: Avoid removing the mouthpiece or the coil while the aforementioned parts are still hot. It can affect the integrity of the components and it might cause minor burns.

Removing the Coil of the Yocan Zen Wax Vaporizer

1. Make sure that the Yocan Zen Wax Vaporizer is powered off and has cooled down.
2. Remove the mouthpiece.
3. Twist the coil counterclockwise to loosen it from the base.
4. Take a brand-new coil and screw it in clockwise.
5. Place the mouthpiece back on top of the base.

Vaping with the Yocan Zen Wax Vaporizer

1. Make sure that you’ve fully charged the battery, installed your selected coil correctly, and loaded the Yocan Zen Wax Vaporizer with your select wax concentrates.
2. Press the power button five times quickly to activate the battery.
3. Press and hold the power button to vaporize your wax concentrates.
4. Repeat this process as necessary or until the extracts in the atomizer are consumed.

Changing the voltage level of the Yocan Zen Wax Vaporizer

1. Make sure that the Yocan Zen Wax Vaporizer is powered on, press the power button five times quickly if not.
2. Press the power button three times to switch to your desired voltage setting.
3. Once you have decided, just leave the button untouched and it will register your chosen voltage setting.

Yocan Zen Wax Vaporizer Voltage Levels:

• 2.8 Volts
• 3.2 Volts
• 3.6 Volts

Yocan Zen Wax Vaporizer Light Setup

• 2.8 Volts (White Light)
• 3.2 Volts (Green Light)
• 3.6 Volts (Red Light)

Removing and Replacing the Mouthpiece of the Yocan Zen Wax Vaporizer

1. Pull the Yocan Zen Wax Vaporizer’s mouthpiece until the magnetic attraction is no longer present.
2. Place the mouthpiece and device close together to create a magnetic connection.

Note: You can clean the base of the magnetic connection when you remove the mouthpiece. This will help you enjoy clean sessions.

Care and Maintenance of the Yocan Zen Wax Vaporizer

The Yocan Zen Wax Vaporizer is made with relatively few parts making it a device that’s easy to take care of. Follow the steps below on how you can clean and take care of your Yocan Zen Wax Vaporizer.

1. Wipe off any dirt or residue on the Yocan Zen Wax Vaporizer battery using a dry paper towel or some alcohol wipes. Continue to reassemble the vaporizer.
2. Follow the charging instructions and use the dedicated charging cable to prolong the Yocan Zen Wax Vaporizer.
3. For maintaining the coils, make sure to refrain from using any hard objects to tamper with the heating element. In the event of a damaged coil, remove it and replace it with a new one immediately.
