Yocan Dive Vaporizer Manual

Preparing the Yocan Dive Vaporizer

1. For best results, ensure that the battery of the Yocan Dive Vaporizer is fully charged before use.
2. After the Yocan Dive Vaporizer is fully charged, power it on by clicking the power button 5 times. Note: The power button is the rectangular button located at the middle part of the battery facing outwards.
3. Once the Yocan Dive Vaporizer is turned on, proceed by sterilizing the touch style heating element. You can do this by pressing and holding the rectangular power button for 5 seconds two or three times consecutively. Note: perform sterilization during the first time you receive your Yocan Dive Vaporizer. This will eliminate and get rid of any impurities that might have made its way to the heating chamber during the manufacturing process.
4. After finishing the sterilization process of the heating element, you can let the Yocan Dive Vaporizer sit and rest for about 2 – 3 minutes. After so, you can start using your Yocan Dive Vaporizer to vape concentrates straight right out of your container or anywhere you keep your concenrates.

Loading the Yocan Dive Vaporizer

Since the Yocan Dive Vaporizer was designed for dabbing in a way where it mimics the functionalities of a nectar collector, there is no need for loading the vaporizer.

1. Set your materials on a parchment paper, a container, a dab mat, or any receptacle where you can easily reach it and dip your Yocan Dive Vaporizer. Note: Use low temperature settings when dabbing on a parchment paper or when dabbing right out of a dab mat.
2. Make sure you’ve prepared your Yocan Dive Vaporizer first if it’s the first time you’re using it. Note: Follow steps for preparing the Yocan Dive Vaporizer.
3. Once your concentrates and your Yocan Dive Vaporizer is ready, you can now start your vaping session.

Switching Through the Temperature Settings

1. Power the Yocan Dive Vaporizer on by clicking the power button 5 times.
2. You can check if the proper action has been performed by looking at the power button itself, it will blink or flash.
3. Tap the power button three times to toggle in between heat settings.
4. Release the power button to allow the selected heat setting to take effect on the Yocan Dive Vaporizer.

Below are the corresponding heat settings and their respective voltage levels.

• Red Light: Low Setting
• Green Light: Medium Setting
• White Light: High Setting

Voltage Level

• Low Setting: 3.5 V
• Medium Setting: 3.8 V
• High Setting: 4.2 V

Vaping with the Yocan Loaded Vaporizer

1. Make sure that the Yocan Dive Vaporizer is correctly sterilized and is fully charged before vaping.
2. Once you’ve secured your materials and a fully charged battery, you may proceed with vaping by holding up your wax concentrate jar or bending down to have the Yocan Dive Vaporizer’s touch style coils reach your concentrates on your parchment paper or on your dab mat. Note: Use low temperature settings when dabbing on a parchment paper or when dabbing right out of a dab mat.
3. Remove the magnetic base cap to expose the touch style coils.
4. Press and hold the power button at the same time as you dab right out of your container and as the Yocan Dive Vaporizer begins producing vapors you may inhale and draw from the mouthpiece.
5. Repeat this process as necessary or as the concentrates are fully consumed.

Care and Maintenance of the Yocan Dive Vaporizer

The Yocan Dive Vaporizer have significantly few parts making it a solid device and is likewise effortless to clean and maintain. To clean your Yocan Dive Vaporizer, follow the steps below.

1. Remove the magnetic base cap.
2. Power the Yocan Dive Vaporizer on.
3. Keep the Yocan Dive Vaporizer in its original upright position where the coils are pointing downwards.
4. Carry out a coil burn-off by pressing and holding the power button for 5 seconds. Repeat this process 2 – 3 times consecutively or until the coils are clean. This will cause any buildup to melt or evaporate.
5. Let the vaporizer cool down.
6. Wipe off the Yocan Dive Vaporizer and the parts with a dry paper towel and replace the magnetic base cap.
