Yocan Stix 2.0 Vaporizer Pen Manual

Preparing the Yocan Stix 2.0 Vaporizer Pen

1. Fully charge your Yocan Stix 2.0 Vaporizer Pen’s battery for best results. Connect the USB charging cable to a computer or a wall adapter and the micro-USB tip to the vaporizer (the charging port can be found on the bottom of the device).
2. Once you have fully charged the battery, you can start using the Yocan Stix 2.0 Vaporizer Pen by simply drawing air from the mouthpiece of the cartridge.

Note: The Yocan Stix 2.0 Vaporizer Pen does not have buttons and operation is carried out by inhaling from the device or slapping the device to the palm of your hands.

Loading the Yocan Stix 2.0 Vaporizer Pen

1. Prepare your select oils. Use dropper to transfer the oils from a container to the pre-installed cartridge. If you have a pre-loaded cartridge, simply connect the end of the cart to the 510-threaded link of the Yocan Stix 2.0 Vaporizer Pen’s battery.
2. Check if the Yocan Stix 2.0 Vaporizer Pen is on by pulling from the mouthpiece.
3. You are ready to vape.

Vaping with the Yocan Stix 2.0 Vaporizer Pen

1. Make sure that the Yocan Stix 2.0 Vaporizer Pen is fully charged and that you have prepared your select oils before you start vaping.
2. Select your preferred voltage setting by slapping the battery gently on the palm of your hands.
3. Select your preferred mode by slapping the battery gently on the palm of your hands.
4. Prepare to inhale from the mouthpiece when you have decided on your preferred settings.
5. Repeat this process until you are satisfied or until the oils in the cartridge are consumed.

Changing the Temperature Level of the Yocan Stix 2.0 Vaporizer Pen

1. Make sure that the Yocan Stix 2.0 Vaporizer Pen is charged and the lights at the bottom of the battery react when you slap it on your hands.
2. Slap the battery and watch out for the lights. One green light means that you are on low setting, two green lights mean you are in medium, and three green lights means you are at high.

Voltage Settings:

• Low – 3.2 volts
• Medium – 3.8 volts
• High – 4.2 volts

Note: Each voltage level is also represented by a dedicated LED light setting allowing you to see the running voltage level from a distance.

Accessing Session Mode

1. You can access Session Mode by pressing the power button two times.
2. Press the power button twice again to stop Session Mode.

Accessing Advanced and Regular Mode

1. You can access either advanced or regular mode by slapping the device five times on your hands.

Note: Advanced mode is represented by green lights while regular mode is represented by red lights. Advanced mode allows you to change the temperature setting while regular mode locks you to a single voltage setting.

Activating Pre-Heat Function

1. You can activate the Yocan Stix 2.0 Vaporizer Pen’s pre-heat functiuon by slapping the battery twice on your hands. Slapping the battery twice, again, cuts off pre-heat mode.

Care and Maintenance of the Yocan Stix 2.0 Vaporizer Pen

The Yocan Stix 2.0 Vaporizer Pen is a portable oil pen that is made with few parts making it an ideal device to travel with that is likewise easy to clean and maintain. The Yocan Stix 2.0 Vaporizer Pen is a simple and straightforward oil vaporizer and requires only a few steps to clean. To maintain your Yocan Stix 2.0 Vaporizer Pen, follow the steps below.

1. Wipe off any dirt or residue on the battery with a dry paper towel.
2. Disassemble the Yocan Stix 2.0 Vaporizer Pen and separate the removable parts.
3. For battery maintenance, make sure to follow charging instructions and use the dedicated charger to avoid damaging the Yocan Stix 2.0 Vaporizer Pen battery.
